For Rockwell Automation 873P Series M30 Analog or Discrete Output Ultrasonic Sensors Replacement Sensing Distance 3500mm Connection Type M12
- Model
- 873P Series | 873P-D30AIP2-3500-D5, 873P-D30AVP2-3500-D5, 873P-D30P1-3500-D4, 873P-D30P2-3500-D5, 873P-D30AIP2-3500-D5
Item specifics
- Series:
- 873P Series
- Size:
- M30
- Sensing Distance:
- 3500mm
- Output Method:
- 1 PNP, 2 PNP, IO-Link, Dual Discrete & One Analog
- Connection Type:
- M12
- Security level:
- IP67
- Material:
- Plastic
Review
Description
For Rockwell Automation 873P Series M30 Analog or Discrete Output Ultrasonic Sensors Replacement Sensing Distance 3500mm Connection Type M12 Parameter
Brand | From network | DADISICK |
|
Models | 873P-D30AIP2-3500-D5 | CSB30-4000-J60-IUEP-IO-V15 | |
873P-D30AVP2-3500-D5 | CSB30-4000-J60-U-V15 | ||
873P-D30P1-3500-D4 | CSB30-4000-J60-E3-V15 | ||
873P-D30P2-3500-D5 | CSB30-4000-J60-E6-V15 | ||
873P-D30AIP2-3500-D5 | CSB30-4000-J60-IUEP-IO-V15 | ||
Thread Size | M30 | M30 | |
Sensing Distance | 250-3500mm, 350-3500mm | 200-4000mm | |
Output Method | Dual Discrete & One Analog (4-20mA); Dual Discrete & One Analog (0-10V DC); IO-Link; 1 PNP Discrete; 2 PNP Discrete | Analog voltage 0-10V;
1 PNP, NO/NC; 2 PNP, NO/NC; IO-Link | |
Connector | M12 | M12 | |
Security level | IP67 | IP67 | |
Material | Plastic | Nickel plating copper | |
We are able to reproduce the specific connection configuration of each brand with high level of accuracy. | |||
Product model display instructions
The brands and specifications shown on this page are for product selection only. Our ultrasonic sensors is a safety part made by DADISICK, not official brand Rockwell Automation's products. DAIDSICK offer replacement for official brand products. We are not the owner of the brands. If you need to buy official brand products, please contact the brand official representative.
Product recommendations
Ultrasonic sensors CSB30 series
Model:
CSB30-4000-J60-IUEP-IO-V15, CSB30-4000-J60-U-V15, CSB30-4000-J60-E3-V15, CSB30-4000-J60-E6-V15
FAQ
1. Can ultrasonic sensors detect transparent or smooth surfaces?
Ultrasonic sensors are capable of detecting transparent or smooth surfaces, although the intensity of the reflected wave may be relatively weak. In these instances, it is crucial to select a more sensitive sensor.
2. How does your product's interchangeability compare with competitors?
Our ultrasonic sensors boast exceptional interchangeability with competitor products. This ensures easy replacement or integration with existing systems, minimizing downtime and ensuring compatibility.
3. Please describe the installation requirements for ultrasonic sensors.
Ultrasonic sensors should be installed in a location that avoids obstructions and reflective surfaces, keeps the transmitting and receiving areas of the sensor clean, and follows the manufacturer's installation guidelines to ensure optimal performance.
